    Electrical Circuits Custom Pcb Board Design , 1oz Pcb Layout Design Services

    Ask Lasest Price
    Brand Name : JIETENG
    Model Number : PCBA
    Certification : ISO/TS16949/RoHS/TS16949
    Price : Negotiable
    Payment Terms : Negotiable
    Supply Ability : 150000 Square Meter/Square Meters per Year
    Delivery Time : 5-8 days for delivery
    • Product Details
    • Company Profile

    Electrical Circuits Custom Pcb Board Design , 1oz Pcb Layout Design Services

    custom pcb board design, pcb layout design services, electrical circuits


    Essential details
    Model Number:
    PCB
    Place of Origin:
    Guangdong, China
    Brand Name:
    JIETENG
    Number of Layers:
    4 Layer
    Base Material:
    FR4
    Copper Thickness:
    1oz
    Board Thickness:
    1.6mm
    Min. Hole Size:
    4mil
    Min. Line Width:
    4mil
    Min. Line Spacing:
    6mil
    Surface Finishing:
    HASL
    Board Size:
    123*108mm
    Max. panel size (finished) (mm):
    880*580
    Max. working panel size (mm):
    914*602
    Max. board thickness (mm):
    12
    Max. layer-up(L):
    40
    Aspect:
    30:1(Min. hole:0.4mm)
    Line wide/space (mm):
    0.075/0.075
    Back drill capability:
    Yes
    Tolerance of back drill (mm):
    ±0.05
    Tolerance of press fit holes (mm):
    ±0.05
    Surface treatment type:
    OSP,sterling silver,ENIG

    Layer
    1~64 Layers
    Material
    FR4, CEM1, CEM3, Hight TG, Rogers, F4B, Taconic, FR1, FR2, 94V0, Aluminum
    Production Capacity
    30000 ㎡/months
    Board shape
    Rectangular, Round, Slots, Cutouts, Complex Irregular
    Board cutting
    Shear, V-Score, Tab-Routed, Counter Sunk
    Board thickness
    0.2~8.0mm, Flex 0.1-0.25mm
    Copper weight
    0.5oZ~12oZ
    Solder Mask
    Double-sided Green LPI, Red, White, Yellow, Blue, Black, Purple etc.Solder mask
    Silk screen
    Double-Sided or Single-Sided in White, Yellow, Black etc
    Min line width/space
    0.08mm/3mil
    Max board dimensions
    25.6inch*43.3inch or 650mm*1100mm
    Min drill hole diameter
    0.1mm
    Min Laser Drill hole diameter
    0.075mm
    Surface finish
    HASL, ENIG, Immersion Tin, Immersion Silver, OSP,ENEPIG etc
    Board thickness toleranc
    ± 10%
    Min slot width
    0.12",3.0mm,or 120mils
    V-score depth
    20-25% of board thickness
    PTH Wall Thickness
    >0.025mm
    PTH Hole Dia Tolerance
    ±0.076mm
    Non PTH Hole Dia Tolerance
    ±0.05mm
    Hole Position Deviation
    ±0.076mm
    Sink holes
    Yes
    Quality Standard
    IPC-A600F/MIL-STD-105D
    Design file format
    Gerber RS-274X, 274D, Eagle and AutoCAD'S DXF,DWG
