    CEM1 Single Sided Multilayer Rogers Smd Circuit Board PCB For Small Electronics

    PCB, single-sided, double-sided, multi-layer Rogers, high-frequency board, PCBA, small electronics


    Essential details
    Model Number:
    PZXPCBA-03
    Type:
    motherboard pcba, Electronic Board
    Place of Origin:
    Shenzhen,China
    Brand Name:
    JIETENG
    Supplier Type:
    OEM PCBA Factory
    Copper Thickness:
    1 oz, 1 Oz
    Application:
    Electronics Device
    Certificate:
    ROSH. ISO9001
    Board Thickness:
    0.2-4mm
    Solder mask:
    Green. Red. Blue. White. Black.Yellow.Grew
    Layer:
    1-12 Layers
    Testing Service:
    AOI X-Ray Function Test
    Material:
    FR4 /aluminum/ceramic CEM1
    Service:
    OEM Services Provided

    ITEM
    TECHNICAL DATA
    ITEM
    TECHNICAL DATA
    Layers
    2-30(layers)
    Min Board Thickness
    4layers:0.40mm/16mil
    Max Board Size
    250x650mm
    6layers:0.80mm/32mil
    Min Line Width
    0.10mm/4mil
    8layers:1.00mm/40mil
    Min Line Space
    0.10mm/4mil
    10layers:1.20mm/48mil
    Min Hole Size
    0.20mm/8mil
    Insulation Resistance
    1E+12Ω(Normal)
    PTH Wall Thickness
    0.020mm/0.8mil
    Aspect Ratio
    10:1
    PTH Dia Tolerance
    ±0.05mm/±2mil
    Thermal Shock
    288℃/3x10Sec@288℃
    NPTH Hole Dia Tolerance
    ±0.025mm/±1mil
    Warp and Twist
    ≤0.7%
    Hole Position Deviation
    ±0.05mm/±2mil
    Electric Strength
    >1.3KV/mm
    Outline Tolerance
    ±0.1mm/±4mil
    Peel Strength
    1.4N/mm
    S/M Pitch
    0.08mm/3mil
    Solder Mask Abrasion
    >6H
    Flammability
    94V-0
    Impedance Control
    ±5%

    Our One-Stop Service

    1, PCB drawing/design according to your schematic diagram.

    2, PCB fabrication.
    3, PCB manufacturing.
    4, Component sourcing.
    5, PCB Assembly - SMT, DIP, Solder, Reflow Solder, Manual work.
    6, PCBA function test.
