    Impedance BGA PCBA Circuit Board Production For Air Cooler

    Ask Lasest Price
    Brand Name : JIETENG
    Model Number : PCBA
    Certification : ISO/TS16949/RoHS/TS16949
    Price : Negotiable
    Payment Terms : Negotiable
    Supply Ability : 50000 Square Meter/Square Meters per Year
    Delivery Time : 5-10 days for delivery
    • Product Details
    • Company Profile

    Impedance BGA PCBA Circuit Board Production For Air Cooler

    PCBA circuit board, Mobile Power PCB board home appliances Bluetooth audio circuit BGA impedance circuit board


    Essential details
    Model Number:
    1103R04024A
    Place of Origin:
    Guangdong, China
    Brand Name:
    JIETENG
    Base Material:
    FR4, CEM1, CEM3, PI, etc
    Copper Thickness:
    18-140um
    Board Thickness:
    0.3-7.0mm
    Min. Hole Size:
    0.1-0.2mm
    Min. Line Width:
    3/3mil
    Min. Line Spacing:
    3/2.5mil
    Surface Finishing:
    LF-HASL, OSP, ENIG, etc.
    Board Size:
    508mm*640mm,610mm*1400mm
    Product name:
    Multilayer PCB
    Layer:
    1-56 Layers
    Application:
    Electronics Device
    Solder mask:
    Green. Red. Blue. White. Black.Yellow
    Certificate:
    ISO9001/ISO14001/ISO13485/TF16949
    MOQ:
    1pcs
    Special Request:
    Impedance Control+BGA

    Item
    Standard(mass production)
    Advanced(Sampling)
    Layers
    1-28Layer
    30-100Layer
    Final Board Thickness
    0.3-3.2mm
    0.15-7.0mm
    Max. Panel Size
    508*640mm
    610*1400mm
    Material
    CEM-3, FR-4, (High CTI, Halogen Free, high frequency), Metal base, Ceramic, Glass base.
    CEM-3, FR-4, (High CTI, Halogen Free, high frequency), Metal base, Ceramic, Glass base.
    Material Supplier
    KB, SY, NY, ITEQ, TUC
    Rogers, Arlon, Taconic, Nelco...
    Surface Finish
    LF-HASL, OSP, ENIG, Immersion Silver, Immersion Tin
    LF-HASL, OSP, ENIG, Immersion Silver, Immersion Tin
    Impedance Control
    ±10% ohm
    ±10% ohm
    Min. Line Width/Space
    3/3mil
    3/2.5mil
    Max. Aspect Ratio
    10: 1
    30:1
    Copper Thickness
    18um, 35um, 70um, 105um, 140um
    140um(inner layer)-280um(outer layer)
    Min. Finshed Hole Size
    0.2mm
    0.1mm
    Soler Mask
    Green, white, black, grey, blue(dark-blue, light-blue), pink, organge, Purple, red, yellow
    Green, white, black, grey, blue(dark-blue, light-blue), pink, organge, Purple, red, yellow

    Impedance BGA PCBA Circuit Board Production For Air Cooler
