    High Frequency Rogers Flexible PCB Prototype Board Fabrication

    Ask Lasest Price
    Brand Name : JIETENG
    Model Number : Rogers FR4
    Certification : ISO/TS16949/RoHS/TS16949
    Price : Negotiable
    Payment Terms : Negotiable
    Supply Ability : 150000 Square Meter/Square Meters per Year
    Delivery Time : 5-8 days delivery
    • Product Details
    • Company Profile

    High Frequency Rogers Flexible PCB Prototype Board Fabrication

    Rogers, high-frequency mixing plate prototype processing

    Essential details
    Place of Origin:
    Guangdong, China
    Base Material:
    FR4/High TG FR-4/M4/ M6/Rogers/Nelco/Isola
    Copper Thickness:
    1 - 4OZ
    Board Thickness:
    0.2 - 4mm
    Min. Hole Size:
    0.15mm
    Min. Line Width:
    0.1mm
    Min. Line Spacing:
    0.1mm
    Surface Finishing:
    OSP,Immersion Gold,Immersion Tin,Immersion
    minimum solder resist opening:
    1.5mil
    minimum solder resist bridge:
    3mil
    maximum aspect Ratio:
    10:01
    impedance control accuracy:
    ±8%
    Certificate:
    ISO9001, ISO16949, ROHS

    Rigid RPCB Manufacturing Capability
    Item
    RPCB
    HDI
    minimum linewidth/linespacing
    3MIL/3MIL(0.075mm)
    2MIL/2MIL(0.05MM)
    minimum hole diameter
    6MIL(0.15MM)
    6MIL(0.15MM)
    minimum solder resist opening (single-side)
    1.5MIL(0.0375MM)
    1.2MIL(0.03MM)
    minimum solder resist bridge
    3MIL(0.075MM)
    2.2MIL(0.055MM)
    maximum aspect Ratio (thickness/hole diameter)
    10:1
    8:1
    impedance control accuracy
    +/-8%
    +/-8%
    finished thickness
    0.3-3.2MM
    0.2-3.2MM
    maximum board size
    630MM*620MM
    620MM*544MM
    maximum finished copper thickness
    6OZ(210UM)
    2OZ(70UM)
    minimum board thickness
    6MIL(0.15MM)
    3MIL(0.076MM)
    maximum layer
    14 layer
    12 layer
    Surface treatment
    HASL-LF,OSP ,Immersion Gold, Immersion Tin ,Immersion Ag
    Immersion Gold,OSP,selectiveimmersion gold,
    carbon print
    Min/max laser hole size
    /
    3MIL / 9.8MIL
    laser hole size tolerance
    /
    10%
