High Frequency PCBs are high-speed circuit boards designed for high-frequency applications. It is made from FR4, with copper thickness ranging from 1 to 4oz, board thickness ranging from 0.2 to 3.2mm, and trace width/space of 3/3 mil. The impedance control of this product is ±10%, making it an ideal solution for high-frequency applications.

Features:

• High-Frequency Circuit Boards
• Min Hole Size: 0.2mm
• Impedance Control: ±10%
• Copper Thickness: 1-4oz
• Packaging: Vacuum Packing, Bubble Bag, Carton Box, Etc.
• Silk Screen Color: White, Black, Yellow, Etc.
• High-Frequency Printed Boards
• High-Speed Printed Circuit Boards
• High-Speed PCBs

Technical Parameters:

Applications:

We are proud to introduce JTETENG's High Frequency PCBs. This high-performance printed board is specifically designed to meet the demanding requirements of high-speed circuit boards, offering unprecedented impedance control, low cross-talk, and signal integrity. Our High Frequency PCBs feature an impressive range of specs, including a ±10% impedance control, 3/3mil min trace width/space, 2-10 layers, 0.2-3.2mm board thickness, and 0.2mm min hole size. With our High Frequency PCBs, you can be sure of reliably high-speed performance and maximum signal integrity.

Customization:

• Brand Name: JTETENG
• Model Number: PCB circuit board
• Place of Origin: China
• Min Trace Width/Space: 3/3mil
• Impedance Control: ±10%
• Min Hole Size: 0.2mm
• Material: FR4
• Board Thickness: 0.2-3.2mm

JTETENG specializes in providing customized service for high-frequency circuit boards, high-speed circuit boards, and high-performance circuit boards. Our high-frequency PCBs come with precise trace width and space, tight impedance control, and min hole size as small as 0.2mm. You can also choose from a variety of material, such as FR4, and board thickness ranging from 0.2mm to 3.2mm. With our professional service and high-precision products, we ensure that you will get the best PCBs for your application.

Support and Services:

High Frequency PCBs are complex and must be designed and manufactured to exacting standards. Our technical support and services team is dedicated to helping you design your high frequency PCBs accurately and efficiently.

Our technical support and services team can advise on the best design for your high frequency PCBs. We can review your design requirements and suggest the best design and components to ensure maximum performance.

Our technical support and services team can assist you during the manufacturing process. We can help you select the best materials and processes to ensure your high frequency PCBs are manufactured to the highest standards.

Our technical support and services team can help you ensure your high frequency PCBs meet all of your performance requirements. We can provide testing and quality assurance services to make sure your PCBs meet the highest standards of quality and reliability.

Packing and Shipping:

High Frequency PCBs Packaging and Shipping:

• High Frequency PCBs are packaged in anti-static bags, and then placed in a static-free container.
• The container is then sealed and labeled with the shipping address.
• The package is then shipped via an appropriate courier.

FAQ:

Q: What is High Frequency PCBs?

A: High Frequency PCBs is a type of printed circuit board produced by JTETENG with model number PCB circuit board. It is made in China and designed to provide high frequency performance and capabilities.

Q: What are the benefits of using High Frequency PCBs?

A: High Frequency PCBs offers improved signal integrity, robust design, and increased reliability for high-speed circuit designs. It also allows for better signal routing and improved thermal performance.

Q: What materials are used in High Frequency PCBs?

A: High Frequency PCBs are usually made with high-frequency materials like ceramic-filled laminates, PTFE (Teflon), and high-frequency metals like copper and silver.

Q: What are the design considerations for High Frequency PCBs?

A: Design considerations for High Frequency PCBs include impedance control, signal integrity, and power/ground plane design. Special attention should also be paid to layer stack-up, trace routing, and vias.

Q: What applications are suitable for High Frequency PCBs?

A: High Frequency PCBs are suitable for applications like 5G networks, radar systems, satellite communications, and other applications that require high-speed signal transmission.

Shenzhen Jieteng Circuit Co., Ltd. is a one-stop service company integrating PCB circuit board prototyping, PCBA, and mass production. The company has engineers with more than 10 years of experience in this industry, providing customers with constructive advice on circuit board production to avoid hidden dangers, provide high-quality PCB circuit board production, and reduce the loss rate of PCB circuit boards. PCBs procured by customers, as well as complaint rates and procurement costs, shorten the customer's procurement cycle. The company's main products include: double-sided and multi-layer fiberglass PCB, polytetrafluoroethylene PCB, polyimide flexible board FPC and aluminum substrate PCB. Products are widely used in high-tech education fields such as communications, power supply, computer networks, digital products, industrial control, science and education, lighting, aerospace, and national defense. Our customers are all over the world, including the United Kingdom, Russia, Brazil, Australia, South Korea, etc. We welcome friends from all walks of life to visit, provide guidance and negotiate business.
